Single Girder Gantry Crane

Lifting Capacity3-50t
Span5~31.5m
Lifting height6~30m
Work levelA3,A4
CertificationCE,ISO,EAC
Whatsapp+8615003858661
Emailinfo@jurencranes.com

Description

MH Single Beam Gantry Crane

Single girder gantry crane, it is a rail traveling medium type crane, it uses together with MD1,CD1 type electric hoist. It is composed of beam, support legs, crane travelling mechanism, trolley, electric equipment and so on.It could be special design and customize by clients' requirement.

Advantages

Simple and compact structure, steady performance.
Easy to install and high efficiency.
Overload, low voltage protective device.
Pendent control and remote control.
Easy maintenance.

Specification

Capacity (t)			3	5	10	16	20
Span (m)			12, 16, 20, 24, 30
Operational method			Pendent Line With Press Button /Cabin/ Remote
Speed (m/min)	Lifting		8 ,8/0.8	8,8/0.8	7,7/0.7	3.5	3.5
	Cross travelling		20	20	20	20	20
	Long travelling	Ground	20	20	20	20	20
		Cabin	20,30,45	20,30,40	30,40	30,40	30,40
Motor (Kw)	Lifting		ZD41-4/4.5	ZD141-4/7.5 ZDS10.8/4.5	ZD151-4/13 ZDS11.5/4.5	ZD151-4/13	ZD152-4/18
			ZDS1-4/0.4/4.5
	Cross travelling		ZDY12-4/0.4	ZDY121-4/0.8	ZDY21-4/0.8×2	ZDY121-4/0.8×2	YZD-4/0.8×4
	Long travelling	Ground	ZDY21-4/0.8×2	YZY22-4/1.5×2	YZR22-4/1.5×2	YZR160M1-6/6.3×2	YZR160M1-6/6.3×2
			ZDY21-4/1.5×2	YZR132M2-6/3.7×2		YZR160M2-6/8.5×2	YZR160M2-6/8.5×2
		Cabin	ZDR100-4/1.5×2	YZR112L1-4/2.1×2	YZR112L1-4/2.1×2	YZR160M2-6/8.5×2	YZR160M2-6/8.5×2
			ZDR112-4/2.1×2	YZR160M1-6/2.1×2	YZR160M2	YZR160L2-6/11×2	YZR160L2-6/11×2
Electric hoist (Model)			CD1/MD1	CD1/MD1	CD1/MD1	CD1	MD1
Lifting height (m)			6, 9, 12, 18, 24,30
Working duty			A3
Power supply			380V 50HZ 3phase AC (According to your demand )
